Communicating via HDLC over a TDM Interface with a QUICC Engine™ UCC, Rev. 0
Freescale Semiconductor 3
Introduction
Although a detailed understanding of both the e300 core and system interface unit are required for use of
the MPC8360, the focus of this applications note is on the QUICC Engine block.
Figure 1. MPC8360E Block Diagram
Note that other QUICC Engine block-based devices from Freescale have a similar architecture, with
different CPU cores and/or speed options, different system interface options, and different QUICC Engine
block performance and I/O options.
1.2 Review of TDM and HDLC
A time division multiplexed (TDM) bus is commonly used in telecommunication systems. A T1 line is a
type of TDM interface developed for digital transmission of voice between telephone switching offices in
Memory Controllers
GPCM/UPM/SDRAM
32/64 DDR2 Interface Unit
PCI Bridge
Local Bus
Bus Arbitration
DUART
Dual I2C
4 Channel DMA
Interrupt Controller
Protection & Configuration
System Reset
Clock Synthesizer
System Interface Unit
(SIU)
Local Bus
Baud Rate
Generators
48 KB Multiuser RAM
Interrupt Controller
UCC8
Timers
Accelerators
Dual 32-bit RISC CP
Serial DMA
2 GMII/
RGMII/TBI/RTBI
8 MII/
RMII/NMSI
8 TDM Ports
2 UTOPIA/POS-PHY
(MPHY 124 Ports)
Parallel I/O
QUICC Engine™ Block
JTAG/COP
Power
Management
Timers
FPU
Classic G2 MMUs
32 KB
D-Cache
32 KB
I-Cache
Security Engine
e300c1 Core
PCI
DDRC1
UCC7
UCC6
UCC5
UCC4
UCC3
UCC2
UCC1
MCC
USB
SPI2
Time Slot Assigner
DDRC2
SPI1
32 DDR2 Interface Unit
48 KB Instruction RAM
Parallel I/O
