MC56F8006/MC56F8002 Family Configuration
MC56F8006/MC56F8002 Digital Signal Controller, Rev. 4
Freescale Semiconductor 3
1 MC56F8006/MC56F8002 Family Configuration
MC56F8006/MC56F8002 device comparison in Table 1.
Table 1. MC56F8006 Series Device Comparison
Feature
MC56F8006 MC56F8002
28-pin 32-pin 48-pin 28-pin
Flash memory size (Kbytes) 16 12
RAM size (Kbytes) 2
Analog comparators (ACMP) 3
Analog-to-digital converters (ADC) 2
Unshielded ADC inputs 6776
Shielded ADC inputs 9 11 17 9
Total number of ADC input pins
1
1
Some ADC inputs share the same pin. See Ta b le 4 .
15 18 24 15
Programmable gain amplifiers (PGA) 2
Pulse-width modulator (PWM) outputs 6
PWM fault inputs 3443
Inter-integrated circuit (IIC) 1
Serial peripheral interface (SPI) 1
High speed serial communications interface (SCI) 1
Programmable interrupt timer (PIT) 1
Programmable delay block (PDB) 1
16-bit multi-purpose timers (TMR) 2
Real-time counter (RTC) 1
Computer operating properly (COP) timer Yes
Phase-locked loop (PLL) Yes
1 kHz on-chip oscillator Yes
8 MHz (400 kHz at standby mode) on-chip ROSC Yes
Crystal oscillator Yes
Power management controller (PMC) Yes
IEEE 1149.1 Joint Test Action Group (JTAG) interface Yes
Enhanced on-chip emulator (EOnCE) IEEE 1149.1 Joint
Test Action Group (JTAG) interface
Ye s
